Energy solutions. Everywhere, every time.

We deliver innovative technology driven by decarbonization, decentralization, and digitalization to help lead the way to a greener future.

As a leading provider of renewable gas, natural gas, and hydrogen-rich solutions, we help to provide communities, industry and the public access to sustainable, reliable and economical power ranging from 200 kW to 10 MW.

Jenbacher gas engines

gigawatts

countries.

CLICK HERE TO REGISTER

CLICK HERE TO REGISTER

CLICK HERE TO REGISTER
INNIO´s Jenbacher engines can operate with variable hydrogen-natural gas mixtures, or with 100% hydrogen
Hydrogen Power Generation Solutions from INNIO.
Want to know more? Click here.

Power solutions suitable for any industry

Agriculture & Food Processing

Keep up the pace using organic waste.

Learn more

Automotive Manufacturing

Power generation and combined heat and power for the automotive industry.

Learn more

Commercial & Industrial Buildings

Optimize your company’s energy OPEX with combined heat and power solutions.

Learn more

Data Center

You have important data. We do, too.

Learn more

Fast Power & Resiliency

Respond with agility and reliability.

Learn more

Greenhouse

Energy, it’s in our nature.

Learn more

IPPs & Utilities

Efficient, reliable power is fundamental to growth.

Learn more

Landfill and Wastewater Treatment

Waste not, want not - turn your waste into energy.

Learn more

Mining

Making coal mining cleaner.

Learn more

Oil and Gas

Overcome industry challenges

Learn more

Steel Industry

Chemistry is a fact of life. It’s a fact of energy, too.

Learn more

Agriculture & Food Processing

Automotive Manufacturing

Commercial & Industrial Buildings

Data Center

Fast Power & Resiliency

Greenhouse

IPPs & Utilities

Landfill and Wastewater Treatment

Mining

Oil and Gas

Steel Industry

Our Gas Engines

Jenbacher Type 2

The stationary engine concept provides excellent durability, while enhanced components and a proven control and monitoring model give the Type 2 engine outstanding reliability.

Technical specifications:

50 Hz

60 Hz

Electrical Output294kW - 330kW
Thermal Output363kW - 409kW
Electrical Efficiencyup to 38.8%
Thermal Efficiencyup to 52%
Voltage400V, 6.3kV, 10.5kV, etc.
Fuel TypeFlexible
Electrical Output335kW
Thermal Output423kW – 424kW
Electrical Efficiencyup to 37.2%
Thermal Efficiencyup to 47.1%
Voltage480V – 600V
Fuel TypeFlexible

Factsheet Type 2 (EN)US Factsheet Type 2 (EN)

Jenbacher Type 2,Learn more
Jenbacher Type 3

Long service intervals, a maintenance-friendly engine design, and low fuel consumption ensure maximum efficiency, while enhanced components prolong service life—even when employing non-pipeline gases such as landfill gas.

Technical specifications:

50 Hz

60 Hz

Electrical Output598kW - 1067kW
Thermal Output508kW - 1321kW
Electrical Efficiencyup to 41.4%
Thermal Efficiencyup to 51.2%
Voltage400V, 6.3kV, 10.5kV, etc.
Fuel TypeFlexible
Electrical Output657kW – 1062kW
Thermal Output635kW – 1399kW
Electrical Efficiencyup to 39.4%
Thermal Efficiencyup to 50.4%
Voltage480V – 4.16kV
Fuel TypeFlexible

Factsheet Type 3 (EN)US Factsheet Type 3 (EN)

Jenbacher Type 3,Learn more
Jenbacher Type 4

Enhanced control and monitoring provide easy maintenance capabilities, as well as excellent reliability and availability.

Technical specifications:

50 Hz

60 Hz

Electrical Output899kW - 1500kW
Thermal Output951kW - 1812kW
Electrical Efficiencyup to 43%
Thermal Efficiencyup to 50.1%
Voltage400V, 6.3kV, 10.5kV, etc.
Fuel TypeFlexible
Electrical Output851kW – 1,429kW
Thermal Output980 – 1,702kW
Electrical Efficiencyup to 41.5%
Thermal Efficiencyup to 48.1%
Voltage480V – 13.8kV
Fuel TypeFlexible

Factsheet Type 4 (EN)US Factsheet Type 4 (EN)

Jenbacher Type 4,Learn more
Jenbacher Type 6

The 1,500-rpm engine speed results in a high power density with low installation costs, and its pre-combustion chamber achieves high efficiency with low emissions.

Technical specifications:

50 Hz

60 Hz

Electrical Output2000kW - 4404kW
Thermal Output1896kW - 4263kW
Electrical Efficiencyup to 46.5%
Thermal Efficiencyup to 47.4%
Voltage400V, 6.3kV, 10.5kV, etc.
Fuel TypeFlexible
Electrical Output1,979kW – 4,381kW
Thermal Output1,896kW – 4,394kW
Electrical Efficiencyup to 46.3%
Thermal Efficiencyup to 43.3%
Voltage480V - 13.8kV
Fuel TypeFlexible

Factsheet Engine Type 6 - English US Factsheet Type 6 (EN)

Jenbacher Type 6,Learn more
Jenbacher J624

INNIO’s Jenbacher J624. Providing a new level of engineering excellence, the J624 offers you significant advantages, particularly in the area of multiple engine power plants for independent power generation and combined heat and power (CHP) solutions.

Technical specifications:

50 Hz

60 Hz

Electrical Output4404kW
Thermal Output4057kW - 4263kW
Electrical Efficiencyup to 46.5%
Thermal Efficiencyup to 47.4%
Voltage400V, 6.3kV, 10.5kV, etc.
Fuel TypeNatural Gas
Electrical Output4,369kW – 4,381kW
Thermal Output4,076kW – 4,394kW
Electrical Efficiencyup to 46.3%
Thermal Efficiencyup to 43.3%
Voltage4.16kV – 13.8kV
Fuel TypeNatural Gas

Factsheet Engine Type 6 - English

Jenbacher J624,Learn more
Jenbacher J920 FleXtra

This Jenbacher gas engine is designed to support a broad variety of multiple-engine power plant solutions–from remote power supply to combined heat and power (CHP) generation.

Technical specifications:

50 Hz

60 Hz

Electrical Outputup to 10400 kW
Thermal Outputup to 10021 kW
Electrical Efficiencyup to 48.7%
Thermal Efficiencyup to 45.3%
Voltage400V, 6.3kV, 10.5kV, etc.
Fuel TypeNatural Gas
Electrical Output9,352kW
Thermal Output7,472kW
Electrical Efficiencyup to 49.3%
Thermal Efficiencyup to 39.4%
Voltage4.16kV – 13.8kV
Fuel TypeNatural Gas

Jenbacher J920 FleXtra,Learn more

Our Services

Jenbacher Gas Engine Services

Bringing proven outcomes across the life cycle of your gas engines means less unplanned downtime, greater workforce efficiency, and lower operating costs. From commissioning to overhauling, our global network of qualified service experts provides the support you need, when you need it, by providing the latest technology.

Learn moreabout Jenbacher gas engine services
